Model |
TRS-C500 |
|
1st axis |
Rated handling capacity(kg) |
2500 |
|
Rated output torque(N*M) |
4198.8 | |
|
Rated moment of inertia GD＾2/4(kg*m＾2) |
1460.3 | |
|
Rotating angle(°) |
±180° | |
|
Rotating speed(degree/sec) |
42.8°/sec | |
|
2nd /3rd axis |
Rated handling capacity(kg) |
500 |
|
Rated output torque(N*M) |
1078 | |
|
Rated moment of inertia GD＾2/4(kg*m＾2) |
292.9 | |
|
Rotating angle(°) |
±360° | |
|
Rotating speed(degree/sec) |
56°/sec | |
|
Rotating radius(mm) |
600 mm /800mm | |
|
Clamperinstallation length(mm) |
1100mm/1300mm | |
|
Allowable clamper weight(kg) |
500+500 |
