Track width (mm) |
4000 |
4500 |
5000 |
5500 |
6000 |
|
Effective cutting width (mm) |
3100 |
3600 |
4100 |
4600 |
5100 |
|
Overall width of machine (mm) |
4800 |
5300 |
5800 |
6300 |
6800 |
|
Effective cutting length (mm) |
Rail length—2500 (Can be customized) |
||||
|
Deflection angle of cutting torch (°) |
-45～＋45 |
||||
|
Groove type |
Groove-V, Groove-X or Groove-Y, Variable angle bevel |
||||
|
CNC system |
EDGE Connect |
||||
|
Optional fine plasma power source |
Hypertherm or Kjellberg |
||||
|
Nesting software |
Australia Fastcam software |
||||
Note: The above parameters are for TIME standard product configurations, and can be customized according to the customer’s requirements.
