Model |
TDMAW-300 |
TDMAW-600 |
TDMAW-1000 |
TDMAW-1600 |
|
Outer diameter of nozzle (mm) |
Φ100～Φ300 |
Φ250～Φ600 |
Φ450～Φ1000 |
Φ850～Φ1600 |
|
Height of nozzle (mm) |
150～200 |
150～450 |
300～600 |
300～600 |
|
Pipe Dia. / Nozzle Dia. |
≥3 |
≥3 |
≥3 |
≥3 |
|
Saddle value (mm) |
≤50 |
≤50 |
≤90 |
≤180 |
|
Lifting stroke of torch (mm) |
120 |
240 |
300 |
400 |
|
Preheating temperature (°C) |
≤200 |
≤200 |
≤250 |
≤250 |
|
Tilt angle of welding torch (°) |
±15 |
±15 |
±15 |
±15 |
|
Max. thickness of pipe (mm) |
≤100 |
≤200 |
≤250 |
≤300 |
|
Rotating speed (r/min) |
0.2～2 |
0.1～1.5 |
0.07～0.7 |
0.01～0.4 |
|
Wire diameter (mm) |
Φ1.2～Φ1.6 |
Φ2.4～Φ3.0 |
Φ3.0～Φ4.0 |
Φ3.0～Φ4.0 |
|
Rated welding current (A) |
400 or 630 |
630 or 1000 |
1000 or 1250 |
1000 or 1250 |
|
Duty cycle |
60% |
100% |
100% |
100% |
Note: The above parameters are for TIME standard product configurations, and can be customized according to the customer’s requirements.
