Characteristics:
● IGBT inverter technology
● Wide range of power supply
● Good product consistency
● Pulse frequency is adjustable
● With variety of TIG operation mode
● High frequency arc ignition, welding penetration well
● Performance stable, strong anti-interference ability
● Thermal design is reasonable to protect the machine perfectly
● Digital display for current to accurate preset welding current before welding
● With MMA function (200A above model)
● Two TIG mode: DC TIG or Pulse TIG
●DSP digital welding machine;
●RS-485 communication socket match RC-6,RC-7 remote controller;
● The welding cables can be lengthened to 50~100M/50mm2
|
Model |
WSM-315 |
|
Company type |
PNE61-315P |
|
Rated input voltage(V) |
3 phase 380V±15% 50~60Hz |
|
Rated Input capacity (KW) |
17 |
|
No-load voltage (V) |
60±5% |
|
Output current adjusting range(A) |
5~315 |
|
Pulse frequency (Hz) |
0.1~500 |
|
Thrust current range(MMA) |
0~1500A/ms |
|
Slope up time (s) |
0.1~99.9 |
|
Slope down time (s) |
0.1~99.9 |
|
Spot time (s) |
0.01~9.99 |
|
Pre-flow time (s) |
0~13 |
|
Post-flow time (s) |
0.1~50 |
|
Pulse ratio range |
0.1%~99% |
|
Duty cycle (40℃) |
60% |
|
Power factor |
0.93 |
|
Efficiency |
85% |
|
Insulation grade |
F |
|
Case protection grade |
IP21S |
|
Cooling |
Wind |
|
Dimensions (mm) |
560×300×530 |
|
Net weight (kg) |
34 |
