Groove depth (mm) |
350 |
|
Groove angle (°) |
circumferential: 1~2 Longitudinal: 3~5 |
|
Min. groove width (mm) |
18~22 |
|
Diameter of workpiece (mm) |
inside welding:：≥Φ2000 Outside welding:≥Φ600 |
|
Pass number per layer |
Two on one layer (single on the first layer) |
|
Load capacity of cross slide (kg) |
500 |
|
Cross slide stroke (mm) |
Horizontal: 300 Vertical: 300 |
|
Cross slide speed (mm/min) |
0～600（Servo speed regulation） |
|
Tracking accuracy (mm) |
Horizontal: ≤±0.2 Vertical: ≤±0.5 |
|
Deflection range of torch (°) |
≤±10 |
|
Deflection speed of torch (r/min) |
0～300 |
|
deflection accuracy (°) |
±0.01 |
|
Wier diameter (mm) |
3.2 or 4.0 |
|
Wire straightening accuracy (mm) |
≤±1 (extension length of welding wire is 40mm) |
|
Rated current (A) |
1000 or 1250 |
|
Duty cycle |
100% |
|
Rated voltage (V) |
44 |
|
Preheating temperature(°C) |
300（weld attachment） |
Note: The above parameters are for TIME standard product configurations, and can be customized according to the customer’s requirements.
