Main characteristics:
● IGBT inverter technology
● Automatically adapt to the grid input
● Low no-load voltage, more safety
● For the acidic and alkaline rod ≤Φ4.0
● Arc force current given automatically so as to operate easily
● Pulse width current control technology to optimize the characteristics of power source to meet the welding process
● Portable for Convenient handling
● ETL approva
● Metal shell
|
Model |
TAZ1605A |
TAZ2105A |
|
Rated input voltage(V) |
AC120V / 240V±15% 50~60Hz |
AC240V±15% 50~60Hz |
|
Rated input current (A) |
20.7 / 27.8 |
43.4 |
|
No-load voltage (V) |
91 |
85 |
|
Output current adjusting range(A) |
20～65 / 20～160 |
25～210 |
|
Duty cycle (40℃) |
20% / 30% |
20% |
|
Efficiency |
85% |
85% |
|
Insulation grade |
H |
H |
|
Case protection grade |
IP21S |
IP21S |
|
Cooling |
Wind |
Wind |
|
Dimensions (mm) |
336×180×265 |
336×180×265 |
|
Net weight (kg) |
6.6 |
6.6 |
